Genlab Classic General Purpose Incubators
The GENLAB range of Classic Incubators offers a selection of highly efficient, reliable and cost effective units to suit most biological analysis, research and general laboratory applications. The simple thermostat system is easy to use and the units can be built up to meet individual requirements.
Genlab Classic Incubator Design
The exterior is constructed from sheet steel finished in an easy clean powder coated paint. The interior chamber is made from mild steel coated with aluminium (CLAD) with a stainless steel (SS) chamber available as an option.
Fitted with fixed shelf runners and removable chrome plated wire grid shelves.
The incubators have an insulated door as standard.
As an option a door with an integral viewing window (VIS) can be fitted, or as an alternative, a double door (DD) which comprises of a steel outer with an inner glass door, is also available..
Genlab Classic Incubator Heating
Heated by Incoloy sheathed elements, positioned below the chamber floor for natural convection units and fitted around the fan on the back wall of the chamber for assisted air circulation units.
Genlab Classic Incubator Controls
The control system comprises of a direct reading thermostat and overheat thermostat, both with calibrated scales and tamper proof locks. They also include a mains switch with indicator and heat and overheat indicators.
Options
Ordering
All units have CLAD interior with thermostatic control and overheat.
Where options are required simply add the option code to the original reference.
E.g. MINI/75 with stainless steel interior and fan circulation becomes MINI/75/SS/F.
Contact sales for bespoke options.
Option codes
Stainless steel /SS
Fan circulation /F
Viewing window /VIS
Double Door /DD
Access ports/AP
Stands/STANDS
Stacking Kits/STACK
Traceable Calibration / SPC
Extended Warranty / X1
Specifications
- 7 sizes 6 to 100 litres
- Temperature range:
Ambient +5ºC to 70ºC (natural convection)
Ambient +8ºC to 70ºC (fan assisted)
- Fluctuation +/- 0.25ºC @ 37ºC
- Easy to use thermostatic control
- Independent overheat thermostat
Genlab Classic Incubator Specifications
Genlab ref.
Number |
Capacity
(litres)
|
Internal dims.
(H x W x D cms)
|
External dims.
(H x W x D cms)
|
No. of
Shelves...
Positions
|
Wattage
|
Weight
(kg)
|
|
without fan
|
with fan
|
| MINI/6 |
6
|
15 x 23 x 19
|
39 x 32 x 33 |
N/A
|
1...1
|
150
|
16
|
| MINI/18 |
18
|
26 x 26 x 27
|
52 x 38 x 41
|
N/A
|
2...2
|
350
|
21
|
| MINI/30 |
30
|
24 x 36 x 35
|
50 x 48 x 49
|
50 x 48 x 62
|
2...2
|
500
|
30
|
| MINI/40 |
40
|
32 x 36 x 35
|
58 x 48 x 49
|
58 x 48 x 62
|
2...3
|
500
|
35
|
| MINI/50 |
50
|
33 x 49 x 33
|
59 x 61 x 47
|
59 x 61 x 59
|
2...3
|
500
|
45
|
| MINI/75 |
75
|
33 x 49 x 45
|
59 x 61 x 60
|
59 x 61 x 72
|
2...3
|
750
|
55
|
| MINI/100 |
100
|
45 x 49 x 45
|
71 x 61 x 60
|
71 x 61 x 72
|
3...4
|
750
|
60
|
