Laboratory Ovens

Nickel-Electro Clifton NE9S Digital Lab Oven

Nickel-Electro Clifton NE9S Digital Lab Oven

Temperature Range : Ambient +5°C - 300°C

Clifton lab ovens feature intuitive easy to use controls with a bold illuminated LED display, offering precise temperature control from ambient +5°C to 300°C with timer functions.

These lab ovens can run at set temperature immediately, use run back timer or enable a delay start feature. Can be configured for gravity convection or with variable fan speed providing forced air circulation within the chamber.

The oven chamber is constructed from high quality stainless steel with high efficiency thermal insulation, contained within an outer steel housing with anti-bacterial paint finish.

With energy efficiency in mind, particular attention is paid to robust design, insulation, a tight door closure with silicone seal and hinge design to maintain chamber temperatures with intelligent temperature control.



Temperature Alarm
Over temperature alarm is automatically set 5°C above set point

Temperature Range
Ambient +5°C - 300°C

Temperature Control
PID Digital, LED display showing actual or set temperature, resolution 0.1°C

Chamber convection
Fan speed can be set from 0% gravity convection within the chamber variable to 100% for forced air convection.

Chamber
Comprising of a high quality corrosion resistant stainless steel chamber, with a bright clean finish housed in a durable paint finished outer case. Painted surfaces feature anti-bacterial finish, hygienic coating which actively inhibits bacterial growth, with good chemical resistance.

Stainless Steel Interior
The oven chamber is constructed from high quality stainless steel with high efficiency thermal insulation.

Door Alarm
Door open, heating interrupted, delay before door sounder chimes until door closed, heating resumes.

The NE9 Series comes with a 2 year warranty as standard, we also offer free advice and support for our ovens.
Nickel-Electro Ltd belongs to the Made In Britain association. The symbol on the company’s products gives customers an assurance of quality.
Product Code NE9-15S NE9-32S NE9-56S NE9-112S NE9-240S NE9-400S NE9-750S
Chamber Capacity 15 Litres 32 Litres 56 Litres 112 Litres 240 Litres 400 Litres 750 Litres
Temperature Range Ambient + 5°C - 300°C
Temperature Control PID Digital, LED display showing actual or set temperature, resolution 0.1°C
Temperature Alarm Over temperature alarm is automatically set 5°C above set point
Temperature Fluctuation ±0.4°C at 150°C ±0.8°C at 150°C
Temperature Variation ±1.8°C at 150°C ±2.5°C at 150°C
Temperature Heat Up 150°C 25 Minutes 35 Minutes
Doors Single insulated door, lockable with 2 point door engagement for an even seal Double insulated door, lockable with 2 point door engagement for an even seal
Shelving Locations Available every 20mm vertically
Shelf Maximum Load 10 kg 20 kg
Voltage 230V 50-60Hz 230V 50/60Hz blue power plug 2P+E
Stackable Y N
Feet/Castors Levelling feet Levelling castors
Dimensions
External (mm) 520w x 390d x 600h 600w x 460d x 680h 600w x 605d x 720h 600w x 660d x 980h 800w x 720d x 1160h 1000w x 720d x 1470h 1240w x 810d x 1625h
Internal (mm) 320w x 180d x 240h 400w x 250d x 320h 400w x 400d x 360h 400w x 450d x 620h 600w x 510d x 800h 800w x 510d x 1040h 1040w x 600d x 1200h
