Water Systems

Purite Fusion Water Purification Unit

For clinical laboratory water
Type I / Ultrapure water (UPW) water
The Purite Fusion is a self-contained water purification unit that delivers a flow of purified water to a consistent quality of 18MΩ.cm. It is ideal for the most demanding laboratory processes including life sciences, such as histology, cell and tissue culture, DNA sequencing and IVF.


Purite Fusion | Overview

Designed for all laboratory applications requiring a reliable and consistent supply of purified water to 18.2MΩ.cm, the Purite Fusion water purification unit provides an advanced unit, which is simple to install, use and maintain.

Combining reverse osmosis, deionisation, ultra-filtration and photo-oxidation in a compact, self-contained unit, the Purite Fusion has an intelligent energy-save mode and is available with a range of options. These include: dual water quality Type I and II, remote dispense pod and a choice of external storage tanks, plus a water and energy-saving ECO option.

Purite Fusion | Features

  • Dual water quality available 1-10MΩ.cm (Type-II) and 18.2MΩ.cm (Type-I)

  • Remote Dispense Pod (Optional)

  • Energy saving intelligent stand-by mode

  • Dispense rate of up to 2 litres/min

  • Water quality parameters, TOC, MΩ.cm, °C and flowrate displayed

  • Selectable manual and volumetric dispense feature

  • 5000m.wt cut off internal ultrafiltration for endotoxin, RNase/DNase removal

  • Dual wavelength (185nm/254nm) UV irradiation

  • Integral TOC indicator

  • UV LED disinfection incorporated within the dispense head

  • ECO option now available offering 50% recovery which equates to a significant reduction in water usage and waste

  • WiFi enabled for remote monitoring and operation.



Purite Fusion | Unit Specification

Unit specification 160 320
Width (mm) 440 440
Depth (mm) 560 560
Height (mm) 750 750
Maximum Shipping Weight (kg)* 36 41
Maximum Working Weight (kg)* 51 59

Installation requirements 160 320
Power Single Phase, 110-230V, +/- 10%, 50/60 Hz
Feed Water Potable Potable
Maximum TDS (ppm) 1000 1000
Minimum inlet pressure – psi (bar) 30 (2.1) 30 (2.1)
Maximum inlet pressure – psi (bar) 90 (6.2) 90 (6.2)
Feed water temperature 1-35oC 1-35oC
Product outputs @ 10ºC (l/hr)* 14.4 30
Product outputs @ 25ºC (l/hr)* 24 48
